2024 RawMaxx LPX 12' x 83" - 2143
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_0.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_1.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_2.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_3.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_4.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_5.jpg)
![](/wp-content/uploads/2023/12/2024-rawmaxx-lpx-12-x-83-2143_788_6.jpg)
Get in Touch
Description
2024 Rawmaxx LPX 12' x 83"
LPX Video
The LPX dump trailer, a reliable and sturdy option for hauling heavy loads. With its 5′ x 5″ x 3/8″ angle type tilt frame and 3″ channel cross-members with 16″ spacings, this trailer can handle even the toughest jobs. The scissor lift system, powered by a KTI 12V hydraulic pump, provides smooth and easy operation. The trailer’s safety features, including 3/8″ G70 safety chains and DOT-approved LED lights, ensure the safety of both the driver and other vehicles on the road. The 3-1 spreader gate with EZ slam door latches makes loading and unloading a breeze, while the 6′ slide-in channel ramps allow for easy access. The LPX also includes a convenient tongue tool box and stake pockets for extensions, adding to its versatility. With a manual tarp kit and a spare tire mount located on the right side, this trailer is ready for any job.
Info
Industry
Trailer
Make
RawMaxx
Model
LPX
Trim
12' x 83"
Year
2024
Msrp
13099.89
Price
12810.60
Stock Number
2143
Category
Trailer
Subcategory
Dump Trailer
Condition
New
Location
Poplar Bluff, MO
Vin
3EVBD1221R1112143
Dry Weight
5144 lbs
Color
Desert Tan
Hitch Type
Bumper Pull
Axles
7000 lb axles
Length
12'
Width
83"
Specifications
Length
Overall: 12' | Tongue: 65"
Width
Overall: 83"
Height
Deck: 28" | Side: 22"
GVWR
14,000 lbs.
Dry Weight
5,144 lbs.
Max Load
10,184 lbs.
Finish
Powder Coat
Warranty
Axle: 5 Year Dexter | Structural: 3 Year | Paint: 1 Year
Coupler
2-5/16” Adjustable Ball Coupler
Tongue
8" x 13 lb. I-beam
Safety Chains
3/8" G70 Safety Chains
Frame
Main: 8" x 13 lb. I-beam Frame | Tilt: 5' x 5" x 3/8" Angle
Crossmembers
Main: 4" x 6" x 3/16" Tubing | Tilt: 3" Channel / 16" Spacings
Step
12G formed plate located at the front on both sides
Walls
10G Formed Walls
Floor
7G One Piece Floor
Fenders
12G Diamond Plate Steel
D-Rings
4 D-Rings
Gate/Door
3 Way Doors
Ramps
6' Slide-In Channel Ramps
Pump
KTI 12V Hydraulic Pump
Controller
14' Cable with Control
Cylinder
5" x 16" Cylinder
Tires
Type: Radial Tires | Size: ST235/80R16 | Ply: 10 Ply | Rating: 3,520 lbs.
Wheels
16” Black Mod Wheels
Axles
2 Spring | Rating: 7,000 lbs.
Brakes
Electric
Lights
Side Markers: 3/4" LED Bullet Lights | Rear: DOT Approved LED Lights
Battery
27M Deep Cycle Marine Battery
